Novatel MT 4100 - Cable Wiring Guides

MT 4100 User Guide 40
Cable Wiring Guides
Serial to P2 DB9 Wiring Guide
Connector DB9 Wire Color
6/7 Ground 5 Ground Yellow
22 Rx 2 RXD Brown
10 CTS 8 CTS Purple
20 RTS 7 RTS Blue
21 Tx 3 TXD Red
Serial to P4 DB9 Wiring Guide
Connector DB9 Wire Color
6/7 Ground 5 Ground Yellow
13 RX2DOUT 2 RXD2 Brown
12 TX2DIN 3 TXD2 Red
Pin to I/O Header Wiring Guide
Connector
I/O
Header Function
3 1 1- Wire I/F
4 2 ADC In #2
5 3 ADC In #1
8 4 Digital Input #2
9 5 Digital Input #1
14 6 Digital Output
#2
15 7 Digital Output
#1
16 8 Digital Output
#3
19 9 Digital Input #3
NC 10 No Connect
18 11 Power
6,7 12 Ground
