Novoferm DCC-80 - Menu 4 Further Door Settings; Menu 5 Various Settings

Selection of the photoelectric sensor (menu item36)
1. You can make an auto detection or a manual selection.
ð Auto detection: Press and hold the ⁠button for 5seconds. The setting for the
photoelectric sensor detected by the DCC appears. Briefly press the ⁠button to
accept the indicated configuration or select another configuration using the ⁠
and ⁠buttons.
ð Without auto detection: Use the ⁠ and ⁠buttons to select the desired config-
uration and briefly press the ⁠button to accept the indicated configuration and
complete the setting.
If you have selected the configuration "Photoelectric sensor mounted in the frame",
a position learning cycle is carried out after the menu is closed. ⁠ is shown on
the 7-segment display.
Selection of the pre-limit switch position (menu item37)
NOTICE
Compliance with standard EN12453
Check the switch-off position of the door after every setting you have carried out.
The switch-off setting must correspond to a maximum distance from the ground of
50mm, otherwise compliance with the standard EN12453 is not ensured. This might
result in the loss of certification.
1. Briefly press the ⁠button to indicate the currently set configuration.
2. Set the switch-off position so that a maximum distance of 50mm to the ground
contact is generated. Values between 0 and 10 are provided to you for this pur-
pose. Values of 2 (default setting) to 0 correspond to -10mm to approx. -20mm.
Values from 3 correspond to 10mm to approx. 50mm.
3. Briefly press the ⁠button to accept the indicated configuration and complete
the setting.
Selection of the roll-up protection mechanism (menu item38)
1. Navigate to menu item38 "Roll-up protection mechanism".
2. You can make an auto detection or a manual selection.
ð Auto detection: Press and hold the ⁠button for 5seconds. The setting for the
roll-up protection mechanism detected by the DCC appears. Briefly press the
⁠button to accept the indicated configuration or select another configuration us-
ing the ⁠ and ⁠buttons.
ð Without auto detection: Use the ⁠ and ⁠buttons to select the desired config-
uration and briefly press the ⁠button to accept the indicated configuration and
complete the setting.
6.3Menu4 Further door settings
Selection of the warning time (menu item43)
You have the option of setting different warning times for the opening and/or closing
process. If the status relay is to be active during the warning time, you must also set
value3 in menu item45/46 (selection of function status relay1/2).
Selection of open time and automatic return (menu item44)
You can set the desired open time in this menu item. After the open time has
elapsed, the door automatically starts to close (automatic return). If no photoelectric
sensor is selected in menu item36 (value1), value4 is automatically set as the pho-
toelectric sensor type in menu item36 after selecting an open time. In order to use
the automatic return function, the installation of a photoelectric sensor is required
according to EN12453.
Selection of the function status relay1 and2 (menu items45/46)
The DCC provides the status relayJ12, whose function can be selected in menu
item45. A second, optional status relay can be plugged into slot J10 (option mod-
ule). Then select the function in menu item46 "Selection of the function status re-
lay2".
In case of "Selection5 error state", the relay switches if there is an error in the
emergency release, the slack rope switch safety circuit or the electronic door lock.
Selection6 always switches, except for the errors mentioned above. Selection7
switches the relay when the set maintenance cycles are reached.
6.4Menu5 Various settings
Wireless closing edge RSE (menu items 53,55,56)
NOTICE
After setting and before initial commissioning, check whether the safety devices are
operating correctly.
The RSE system serves as a radio transmission system of the signals from the clos-
ing edge safety device, slack rope switch and wicket door sensor to the drive. The
system is in accordance with PLc in compliance with EN 13849-1.
Please proceed as follows to commission the RSE system:
1. Connect the module to the DCC at slotJ6.
2. Select value1 "RadioSafetyEdge system" in menu item53 "Selection of module
at slotJ6".
3. Select the type of the closing edge safety device in menu item55. "Optical clos-
ing edge safety device OSE" (value1) is preselected as a default value.
4. Select the type of the wicket door in menu item56. "ENS68xx" (value1) is
preselected as a default value.
Pairing of RSE-T and RSE-R
1. Navigate to menu item55.
2. Press and hold the ⁠button for 5seconds.
ð The RSE-R emits a long beep sound for confirmation.
ð Value55 flashes on the 7-segment display(1).
3. Now press the button on the RSE-T.
ð The RSE-R emits a long beep sound for confirmation.
ð The drive confirms pairing by the decimal point flashing for 5times in the LED
display.
