Novoferm DCC-80 - Menu 6 Radio Settings; Menu 8 Profile Settings

Unpairing of RSE-T and RSE-R
WARNING
Impact and crush hazard due to the door movement!
By unpairing the RSE-T and RSE-R, the safety sensors are inoperative.
n Repair the RSE-T and RSE-R again or make sure that the RSE sys-
tem is replaced by a coiled cable.
1. Navigate to menu item56.
2. Press and hold the ⁠button for 5seconds.
ð The RSE-R emits several rapid beep sounds.
ð The drive confirms unpairing by the decimal point flashing for 5times in the LED
display.
Selection of module inputJ9 (menu item54)
In this menu item, connectionJ9 can be configured. The preset value0 for the BTD-K
(Bluetooth) can be changed to internal service functions (1, 2).
Electronic door lock (menu item57)
In this menu item, an electronic door lock (EDL100) can be activated. To do so, set
the value to1.
6.5Menu6 Radio settings
You are provided with the possibility of programming 40"KeeLoq" hand-held trans-
mitter channels. Please observe that every hand-held transmitter must be pro-
grammed individually.
Programming the start button on the hand-held transmitter (menu item60)
1. While the value "60" is flashing on the 7-segment display(1), press the button
of the hand-held transmitter you want to program.
ð Successful programming of the hand-held transmitter is indicated by the
decimal point flashing 5times.
2. To program any additional hand-held transmitters, please repeat the procedure
from point1 or end the configuration by navigating to exit "––" and pressing
the ⁠button.
Programming the button1/2 door opening on the hand-held transmitter
(menu item61)
1. Actuate the button of the hand-held transmitter for 1/2door opening.
ð Successful programming of the hand-held transmitter is indicated by the
decimal point flashing 5times.
2. To program any additional hand-held transmitters, please repeat the procedure
from point1 or end the configuration by navigating to exit "––" and pressing
the ⁠button.
After programming the OPEN and CLOSED door end positions, the 1/2door opening is
automatically calculated and is immediately available. If a different position is de-
sired, set it in menu item32. This function is only possible in the pulse OPEN/ pulse
CLOSE operating mode.
Hand-held transmitter information/ Deleting all radio codes (menu item63)
To read out the number of occupied memory locations, proceed as follows:
1. Briefly actuate the ⁠button.
ð Four digits are output in sequence. The first two digits indicate the number of
occupied hand-held transmitter memory locations. The last two digits indicate
the total number of possible memory locations. Example: Output "2 4 4 0"
means that 24 of 40memory locations are occupied.
To delete all codes programmed, proceed as follows:
2. Press and hold the ⁠button for 5seconds.
ð Successful deleting the hand-held transmitters is indicated by the decimal point
flashing 5times.
6.6Menu8 Profile settings
Selection of the door profile (menu item80)
In this menu item, the door profile that has been selected during the initial installa-
tion can be changed subsequently.
1. Select the appropriate door profile 1-9 (standard fittings 1-3, raised fittings 4-6,
vertical runner 7-9).
2. Confirm the profile selection by pressing the STOP button.
ð Changing the door profile requires a new failure-free force learning cycle in both
the opening and closing direction and after exiting the menu. This will be indic-
ated via the display and the LED on the drive. If a closing edge safety device has
already been selected, there is no need for a new teach-in run.
Force setting opening (menu item81)
WARNING
Danger of entanglement by the moving door!
Force detection does not replace the need for safety measures against
the danger of entanglement!
NOTICE
Compliance with standard EN12453
Any change of the force setting requires a subsequent check of the closing forces
according to EN12453.
The force detection for the opening direction can be adjusted in this menu item. The
smaller the set value (1-10), the more sensitively the drive will react to external in-
fluences on the door.
1. Select the desired force setting (1– "very sensitive" to 10– "insensitive").
2. Confirm the selection with the button ⁠. A new force learning cycle is not re-
quired when changing the force setting.
⁠ If necessary, a new force learning cycle can be initiated by pressing and
holding the ⁠button on menu item81.
Force setting closing (menu item82)
WARNING
Impact and crush hazard due to moving door!
Force detection does not replace the need for safety measures against
impact and crush hazards caused by the descending door.
The force detection for the closing direction can be adjusted in this menu item. The
smaller the set value (1-10), the more sensitively the drive will react to external in-
fluences on the door.
1. Select the desired force setting (1– "very sensitive" to 10– "insensitive")
2. Confirm the selection with the ⁠button. A new force learning cycle is not re-
quired when changing the force setting.
Adjusting the closing speed (menu item83)
Press and hold the ⁠button for 5seconds to access this setting. The maximum
closing speed of the set profile can be fine-tuned here by +/-10%.
14|Novoferm
