Error State Diagnosis / remedy
DCC events
E01 No door movement Roll-up protection mechanism no.1 activated
E02 No door movement Roll-up protection mechanism no.2 activated
E03 No door movement Wicket door open
E04 No door movement Control unit interlocked by external control. Set
bridge at terminal LOCK to option module
E05 No door movement Slack rope switch has triggered
E06 Door reverses Closing edge safety device has tripped
E07 Door reverses Photoelectric sensor has triggered
E08 No door movement Drive has been disengaged
E13 Door reverses Overcurrent detected
E20 Display when fully op-
erational
Runtime limitation reached in a few minutes
E30 Door only closes in
dead man mode
Emergency operation. Check closing edge safety
device or photoelectric sensor
RSE events
E43 No door movement RSE wicket door open
E45 No door movement RSE slack rope switch has triggered
E46 Door reverses RSE closing edge safety device triggered
IPD-S events
E53 No door movement IPD-S bracket wicket door open
E55 No door movement IPD-S slack rope switch has triggered
DCC error
F11 No door movement Error during testing of the current measuring
device
F12 No door movement Current overload detected
F13 No door movement Temperature sensor has triggered, allow drive
to cool down
F15 No door movement Testing of photoelectric sensor has failed
F17 No door movement ENS6800 sensor error detected(J3)
F18 No door movement Short circuit detected in coiled cable line(J3)
F19 Closing impossible Testing of pressure wave switch failed, check
pressure wave rubber profile
F21 Brief operational in-
terruption
Runtime limitation of door drive, let drive cool
down for approx. 20min
F22 No door movement EDL100 not recognised. Check wiring
F23 No door movement Error during locking/unlocking procedure
EDL100
F24 No door movement Communication error with DES
F27 No door movement Drive blockage detected
F28 No door movement Faulty voltage supply
F29 No door movement Wrong rotation direction detected
F31 No door movement Emergency limit switch OPEN approached
Retract the door in a de-energised state using
the emergency manual override
F32 No door movement Travel distance exceeded in time. Check door
for ease of motion
Error State Diagnosis / remedy
RSE error
F40 No door movement RSE module not recognised
F41 No door movement RSE receiver and transmitter are not paired
F42 No door movement RSE radio interference detected
F44 No door movement RSE battery empty
F47 No door movement RSE error ENS6800 sensors
F48 No door movement RSE short circuit detected
F49 No door movement RSE radio duty cycle exceeded
IPD-S error
F56 No door movement IPD-S supply voltage faulty. Check X4, X5, X6
for short circuit
F57 No door movement IPD-S wicket door error
F58 No door movement IPD-S short circuit detected in coiled cable line
Test error
F90-F99
F9B
No door movement Internal testing failed. Switch drive off and on
again
General indication
CS – Maintenance cycles reached
Perform service activity
IA – Control unit inactive
Prioritised position was approached
Return to normal operation by mains reset
Lo – Operation of the drive has been locked
dE – Determining the limit switch type is active
