Check list for door system
(Document equipment during commissioning by ticking the items off)
Equipment Available/
applicable
Properties to be checked OK Comment
1.0 Door
1.1 Manual operation of the door Smooth running .......................................................
1.2 Fastenings/connections State/Seat .......................................................
1.3 Pivots/joints State/Lubrication .......................................................
1.4 Track rollers/track roller holders State/Lubrication .......................................................
1.5 Seals/sliding contact strips State/Seat .......................................................
1.6 Door frame/door guide Alignment/Fastening .......................................................
1.7 Door leaf Alignment/State .......................................................
2.0 Weight counterbalance/safe opening
2.1 Springs State/Seat/Setting .......................................................
2.1.1 Clamping heads / bearing blocks State .......................................................
2.1.2 Spring break device State/rating plate .......................................................
2.1.3 safety elements State/Seat .......................................................
2.2 Wire cables State/Seat .......................................................
2.2.1 Mounting State/Seat .......................................................
2.2.2 Cable drums 2 Safety windings .......................................................
2.2.3 Slack rope switch State/seat/function .......................................................
2.3 Fall protection State .......................................................
2.4 Concentricity of T-shaft State .......................................................
3.0 Drive/ controls
3.1 Drive/console State/Fastening .......................................................
3.2 Electrical cables/connections State .......................................................
3.3 Emergency release State/function .......................................................
3.3.1 Quick chain State/function .......................................................
3.3.2 Crank handle State/function .......................................................
3.3.3 Quick release State/function .......................................................
3.4 Control devices push-button/hand-held transmitter State/function .......................................................
3.5 Limit stop State/function .......................................................
4.0 Safeguarding of crush and shearing zones
4.1 Force limit Stops and reverses .......................................................
4.2 Protection against lifting of persons Door leaf .......................................................
4.3 Site conditions Safely distances .......................................................
5.0 Other devices
5.1 Latching/lock Function/State .......................................................
5.2 Wicket door Function/State .......................................................
5.2.1 Wicket door contact Function/State .......................................................
5.2.2 Door closer Function/State .......................................................
5.3 Traffic light control Function/State .......................................................
5.4 Photoelectric sensors Function/State .......................................................
5.5 Closing edge safety device Function/State .......................................................
6.0 Documentation by the operating company
6.1 Rating plate/CEmarking complete/readable .......................................................
6.2 Declaration of Conformity for the door system complete/readable .......................................................
6.3 Assembly, operating, maintenance manuals complete/readable .......................................................
