NOVUS AUTOMATION www.fieldlogger.net 83/104
%ALARM__001.UNI% Alarm 1 configured condition: “>”, “>=”, “<”, “<=”, “==” or “!=”
%ALARM__001.HYS% Alarm 1 configured unit
... ...
%ALARM__032.TAG% Alarm 32 tag
%ALARM__032.STS% Alarm 32 status: “ON” (active alarm) or “OFF” (not active)
%ALARM__032.SPT% Alarm 32 configured setpoint
%ALARM__032.CND% Alarm 32 configured condition: “>”, “>=”, “<”, “<=”, “==” or “!=”
%ALARM__032.UNI% Alarm 32 configured unit
%ALARM__032.HYS% Alarm 32 configured hysteresis
%INFO.IN.FLTAG_%
FieldLogger tag
%INFO.IN.SERIAL% Serial Number
%INFO.IN.FWVER_% Firmware version
%INFO.IN.MBMODE% Main RS485 interface Modbus mode:
"Disabled", "Master" ou "Slave"
%INFO.IN.MBADDR% Main RS485 interface Modbus address
%INFO.IN.D_TYPE% Selected logging memory: “Flash” or “SD Card”
%INFO.IN.START_% Start logging mode selected:
"Immediately", "Date/Time", "Alarm" ou "Via Modbus Only"
%INFO.IN.STOP__% Stop logging mode selected:
"Full Memory", "Circular Memory", "Date/Time" ou "Alarm"
%INFO.IN.FDRVIN% USB flash drive connection status:
“Yes” (connected) or “No” (disconnected)
%INFO.IN.SDSIZE% SD card memory capacity, in kbytes
%INFO.IN.SDFREE% SD card available free memory, in kbytes
%INFO.IN.INSIZE% Internal flash memory capacity, in bytes
%INFO.IN.INFREE% Internal flash available free memory, in bytes
%INFO.IN.ANLSCN% Analog channels scan interval, in ms
%INFO.IN.LOGPER% Logging interval, in ms
%INFO.IN.LOGSTS% Current logging status: “Logging” or “Stopped”
%INFO.IN.HMICON% HMI connection status: “0” (no HMI) or “1” (HMI connected)
%INFO.RTC.YEAR_% Internal calendar year
%INFO.RTC.MONTH% Internal calendar month
%INFO.RTC.DAY__% Internal calendar day
%INFO.RTC.HOUR_% Internal clock hour
%INFO.RTC.MIN__% Internal clock minute
%INFO.RTC.SEC__% Internal clock second
Examples
There are examples available for download in the product website and also in the product CD.
