NOVUS AUTOMATION www.fieldlogger.net 95/104
The available parameters of this screen are:
FieldLogger: .................................................................................... FieldLogger configuration
Date ........................................................................................... Date configuration
Time ........................................................................................... Time configuration
Ethernet ..................................................................................... Ethernet interface configuration
DHCP Enable ......................................................................... DHCP enabling
IP Address ............................................................................. IP address configuration
Subnet Mask ......................................................................... Subnet mask configuration
Gateway ................................................................................. Gateway address configuration
Modbus RTU .............................................................................. Modbus RTU interface configuration
Mode ...................................................................................... Operation mode: master/slave
Slave Address ........................................................................ Modbus slave address
Baud rate ............................................................................... Communication baud rate
Parity ...................................................................................... Communication parity
HMI.................................................................................................... HMI configuration
Backlight Timeout....................................................................... Time to turn the backlight off (0 = always on)
Chart .......................................................................................... “Chart” screen configuration
Color Background .................................................................. Background color: black/white
Interval ................................................................................... Period of time displayed on the Chart
Reference Value 1 ................................................................. First reference line value*
Reference Value 2 ................................................................. Second reference line value*
Input High Limit ..................................................................... Chart maximum displayed value**
Input Low Limit ....................................................................... Chart minimum displayed value**
* For disabling the reference lines, just configure them to a value out of the input configured range.
** If the Low Limit is configured to a value greater than the High Limit, the Chart will not display the values of the
channels in a correct way!
