SPEED DOME CAMERA - CONNECTION AND CONTROL
Novus camera CAMA I
no 1
Video
Novus camera CAMA I
no 8 (16)
v
24VAC + 24VAC - FGND (RX+) RX+(TX+) RX-(TX-) GND 24VAC- 24VAC+
v
24VAC + 24VAC - FGND (RX+) RX+(TX+) RX-(TX-) GND 24VAC- 24VAC+
Twisted pair UTP 5 max
max 1,5 m max 1,5 m
An example of CCTV system based on NV-DVR1116/CD and Cama series camera
