4.6 Event List
When EVENT LIST is entered system history is available. The system registry stores up to 2000
events recorded from the last HDD formatting. When 2000 number is exceeded the oldest events are
overwritten with the latest events.
When two HDDs are installed in the device there is possibility to store 2000 events on Slave and 2000
events on Master HDD.
Events are classified according to the time of occurrence. Latest events are displayed as first. When
there are more events than can be displayed on one page additional events are displayed on following
system registry pages. HDD and page number, to which registry (event) refers are displayed in the top
of the screen. In order to proceed to following pages please use cursor buttons . in order to
playback records, which are connected with the event, cursor buttons should be used (for
required record selection) and ENTER button should be pressed.
Event information are divided in columns.
The first column consists of event number, second - event date, third - event time, fourth - the event
camera number, which event refers to („--” sign means that event refers to entire system).
The fifth column consists of shortenings describing event type:
− MOTION motion detection activation
− V.LOSS signal loss
− RECORD start recording
− ALARM alarm on the alarm input
− POWER system reboot due to power failure
DEVICE MENU
NO YY / MM /DD HH:MM:SS CH TYPE
01 2006 / 06 / 12 15: 22: 36 01 ALARM
02 2006 / 06 / 12 14: 22: 36 01 V.LOSS
03 2006 / 06 / 12 14: 21: 36 -- RECORD
04 2006 / 06 / 12 13: 12: 34 02 MOTION
EVENT LIST
ENTER -SET
MENU EXIT
MASTER PAGE: 001
