NV-DVR1104/CD, NV-DVR1108/CD and NV-DVR1116/CD ver. 1.1 - user's manual
All rights reserved © NOVUS Security Sp. z o.o.
60
NETWORK CONNECTION FEATURE
12.6 Software settings
In order to enter software settings click icon from right upper corner
In order to return back to main window icon should be clicked.
12.6.1 Software language and Server time settings
In System information submenu following settings can be adjusted:
▪ Software language can be set in Language position
▪ in NTP Setting position all settings required at system time synchronization function can be
adjusted. When Set NTP Server position is selected time server address and time zone can be
set.
In order to introduce changes Apply button should be clicked.
12.6.2 Users passwords and accounts.
Utilizing User Management submenu following settings can be adjusted:
▪ Anonymous User Login position is used to configure if connection with multiplexer should be
done with user’s login or not. To accept selection click Setting button.
▪ User Management position is used to edit users accounts. User’s list with their passwords and
access levels is displayed in the bottom of the window. Admin level is available only for one
user. New user name is input in Username
field and new password is input in Password field.
In Confirm field user’s password should be typed twice and Add/Set should be clicked. In order
to edit users account, highlight user’s name from the list and follow all steps described above.
12.6.3 NC Viewer Download
When Download submenu is clicked NC Viewer file will be downloaded from multiplexer onto PC
12.6.4 IP setting
All network parameters settings are grouped in this tab. The meaning of each parameter was described
in chapter 4.8. Any changes can be adjusted using IP Setting tab. In order to introduce changes Apply
should be selected.
NOTICE: When IP address or port has been changed network will be disconnected. Connection should
be resumed according to newly adjusted parameters.
