Chapter3 Software & config
Manual of NCH02
- 21 -
The single step parameters can be set into 3 gears, which are 1mm, 0.1mm and 0.01mm,
which can be adjusted by the knob.
9, F parameter setting
This parameter defaults to the minimum speed of each axis in the parameter configuration
item, and can be adjusted by the knob. If there is no F instruction in the G code, the G code is
running in this speed. If there is F instruction in the G code, the feed speed is updated according
to the F instruction.
10, F real-time display
F real-time display values show the real-time speed of F during the running of G code.
Real time feed speed #F=FRO*F (set feed speed).
11, S parameter setting
This parameter defaults to the default spindle speed in the parameter configuration item,
which can be adjusted by the knob. If there is no S instruction in the G code, the G code is
running at this speed. If there is S instruction in the G code, then the spindle speed value is
updated according to the S instruction.
12, S real-time display
S real-time display values show the real-time speed of S during the running of G code.
Real time spindle speed #S=SRO*S (set the spindle speed).
13, M10/M11 state display
The state value of the M10/M11 switch is displayed, which can be manually modified by
the knob or automatically modified according to the M10/M11 instruction in the running G file.
14, M8/M9 state display
The state value of the M8/M9 switch is displayed, which can be manually modified by the
knob or automatically modified according to the M8/M9 instruction in the running G file.
www.nvcnc.net
