Novusun CNC NCH02 User Manual

Chapter1 Introduction
Manual of NCH02
- 1 -
Chapter 1. Introduction
1.1 Product Introduction
Novusun CNC has engaged in the Numerical control industry for 7 years, specialized in
the research, development and production of various CNC controller systems with high quality
and high reliability. We produce the Brushless DC motor, Stepper motor driver, and also 1 to 6
axis CNC motion controllers.。
NCH02 is the 5 axis motion controller we spend 2 years to design.
NCH02 is a CNC system without computer. Only need a U-disk within G-CODE file,
NCH02 can read the G file and run the G file.
This manual introduces operation, connection and usage schedule of our professional
motion controller for engraving machine. Through a lot of the drawing the users can learn
quickly how to use this motion controller.
1.2 Products specification
 Read G-CODE from U-DISK;
 Operation without computer;
 8 ports photoelectric isolated input interface；
 5 ports photoelectric isolated output interface；
 1 port 0-10V spindle speed analog output interface(can change to PWM output)；
 can support 5 axis stepper systems,125KHz pulse output for every axis；
 ARM motion control chip；
 main device is 24VDC power supply input, current should higher than 1A；
