Chapter 4. Operation and Application
The basic operation is introduced in the front part of the keystroke. Here is not going to be
exhausted. Here we introduce the use of this product from the perspective of an initial user. The
first time we start the product, we first configure all the configuration items according to our actual
needs. Here we introduce the usage method, no longer describe the configuration items, and all the
configuration items are configured according to the customers' needs.
First of all, the system is started, our first step is to establish the machine coordinate system;
the second step is probe, accurate zero; third step up the workpiece, the tip will move to zero
workpiece, and the workpiece coordinate reset; the fourth step is to load the G file; the above work
is finished, press START to start G code execution. The following sections describe these steps in
detail.
4.1 Establish machine coordinate system
As shown in Figure 4-1, the engraving machine schematic diagram is installed. Each axis is
equipped with a proximity switch. The limit and home share this switch. The X axis switch is
installed in the X-- position. The Y axis switch is installed in the Y++ position; the Z axis switch is
installed in the Z++ position. (here we test the prototype as a reference for installation, the actual
application of the customer can be selected according to the needs of the installation).
