to a color block, the valid color block becomes red, and the
invalid color is blackened.
5 OUTPUT TEST
The output IO value is displayed in real time. One IO
corresponds to a color block, the output block becomes red, and
the invalid color is blackened.
6 TEST ALL
The function is selected by the adjustment knob. After the test is
started (PUSH), all modules are running or changing according
to the design.
7 KEYBOARD
Button monitoring can monitor the press position in real time.
Table 3-9. Description of test and diagnosis page
