Chapter3 Software & config
Manual of NCH02
- 33 -
16 ESTOP PIN
The pin of Estop, 0 for closing, and 1-8 for the
corresponding input pin IN1-IN8
0-8
17 ESTOP LEVEL
Effective level of Estop, 1: high efficiency, 0:
low efficiency
1/0
18 P-B-Z
Back distance of Z axis after Probe in
floating-position mode
0-100
Table 3-8. Other parameter setting
3.4 Test and diagnosis page
The test and diagnosis page can be entered by pressing under the parameter
configuration page. The page mainly displays the basic function test information of the system,
including key monitoring, input and output monitoring, spindle monitoring and so on. Page
reference diagram 3-7. detailed description of reference table 3-9.
www.nvcnc.net
To Next Page
