Page #24 background imageLoading...
Page #24 background image
Chapter3 Software & config
Manual of NCH02
- 22 -
15, M3/M4/M5 state display
The state value of the M3/M4/M5 switch is displayed, which can be manually modified by
the knob or automatically modified according to the M3/M4/M5 instruction in the running G file.
16, G coordinate system display
The current coordinate system is displayed, with a modified range of G54~G59, which can
be manually modified by the knob or automatically modified according to the G54~G59
instruction in the running G file.
17. System status bar
The status bar of the system is mainly prompted by the common system state, and the list
of States is as follows
NO. Display Definition
1 SYSTEM REDAY
The system is ready to execute the G code
2 SYSTEM RESET
System reset state, no operation can be done
3 SYSTEM IS RUNNING
G code is running
4 X++ LIMITED
Positive limit of X axis is triggered. Same as
other axis
5 X-- LIMITED
Negative limit of X axis is triggered. Same as
other axis
6 X++ SOFT LIMITED
Positive soft limit of X axis is triggered. Same
as other axis
7 X-- SOFT LIMITED
Negative soft limit of X axis is triggered. Same
as other axis
Table 3-1. system status prompt information and definition
