NSK Primado2 - Page 26

25
Product Description
English
_ Jacobs Keyed Drill Chuck 4.0mm/6.5mm
Order Code PD-DA-J4 PD-DA-J6
Maximum Rotation Speed min
-1
1,200
Chuck Capacity mm Ø0.5 - 4.0 Ø0.5 - 6.5
Cannulation mm Ø4.2
Dimension of Attachment (ØD x L) mm Ø21 x 93 Ø31 x 108
Applicable Cutting Accessories Commercially available drill bit, wire or pin
with Ø4.0mm or less shank
Commercially available drill bit, wire or pin
with Ø6.5mm or less shank
_ AO Drill Chuck
Order Code PD-DA-A
Maximum Rotation Speed min
-1
1,200
Cannulation mm Ø1.5
Dimension of Attachment (ØD x L) mm Ø25 x 84
Applicable Cutting Accessories Commercially available AO-type drill bit
_ Keyless Drill Chuck
Order Code PD-DA-K
Maximum Rotation Speed min
-1
1,200
Chuck Capacity mm Ø0.6 - 7.4
Cannulation mm Ø4.2
Dimension of Attachment (ØD x L) mm Ø31.5 x 84
Applicable Cutting Accessories Commercially available drill bit, wire or pin with Ø7.4mm or less shank
(L)
(ØD)
(L)
(ØD)
(L)
(ØD)
