Operator-Accessible Maintenance
Incidents
The job reference does not correspond
Do not validate the page. ☞
N
Display of message:
THE AFFAIRE No. DOES NOT CORRESPOND
WITH THE LOCKING CODE
QUIT THE UTILITY: CTRL X-OFF
Return to the "UTILITIES PRESENT" menu. ☞
CTRL
+
S
X OFF
8.9.2 Modification of the Number of Axes and Spindles
The modification consists in entering the new values for the number of axes and spindles taken from the customisation
grid.
Requirements
"S/W OPTIONS SETUP" menu displayed (See 8.9).
Actions
Select "NUMBER OF AXES". ☞
!
1
The "AXES NUMBER" page is displayed:
. . / . . EXIT
AXES NUMBER
NUMBER OF CNC OR PLC AXES : 7
NUMBER OF SPINDLES : 2
NUMBER OF INTERPOLATED AXES : 5
NUMBER OF PLC ONLY AXES : 2
(A,B,IS,XA) ? ❚
