NUM 1020 - 8 Rtcp Function; General

RTCP Function
en-938872/2 8 - 1
8
8 RTCP Function
8.1 General 8 - 3
8.1.1 Control of Rotary Axes 8 - 3
8.1.2 Processing Performed on the Axes 8 - 3
8.2 Using the RTCP Function 8 - 4
8.3 Description of Movements 8 - 6
8.3.1 Description of Twist Heads 8 - 6
8.3.2 Description of Turntables 8 - 8
8.4 Processing Related to the RTCP Function 8 - 9
8.4.1 Part on Inclined Plane 8 - 9
8.4.2 Turntable Off-Centering (DAT3) 8 - 10
8.4.3 Tool Length Correction 8 - 10
8.4.4 Tool Wear Offset 8 - 10
8.4.5 3D Tool Correction (G29) 8 - 10
8.5 Use in JOG and INTERV Modes 8 - 11
8.6 Restrictions and Conditions of Use 8 - 11
