4 - 6 en-938872/2
4.1.4 Creating Tables for Storing Profiles
The system offers the possibility of storing a profile written in ISO or PGP in a table
of the programme stack. The table is created as the profile blocks are read.
The programmed blocks are stored in a table with two dimensions:
- the first dimension includes all the functions to be saved in a block,
- the second dimension corresponds to the number of blocks in the profile.
The data in the table are then accessed by parametric programming.
Example:
Entry 1 Entry 2 Entry 3 Entry 4 Entry 5 etc.
First dimension
Second
dimension
(blocks)
