6.2.4 Limit on the Number of Coefficients
For each block, the coefficients are stored in the programme stack which has a
maximum of 32 entries. Each coefficient is stored in an entry. In addition, for each
axis, one entry is occupied by the physical address of the axis followed by the number
of coefficients.
If the stack becomes full, the system returns the error message 6.
The coefficients have the same format and same limit values as dimensions.
Example:
Storage of the coefficients of a block in the stack.
N20 X100/60/-40/30/-15 Y70/20/-30/5 Z80/-5/20/30/-20/40
4 0 60 -40 30 -15 3 1 20 -30
5
5 2 -5 20 30 -20 40 0
Axis 2, 5 entries
Axis 0, 4 entries Axis 1, 3 entries
