Table of Programme Status Access Symbols
en-938872/2 C - 3
C
Access Symbols to the Data of the Current Block or Previous Block
Only the access symbols to the data of the current block are listed in the table. The
access symbols to the data of the previous block, although not given, are exactly the
same as those for the current block except that they are preceded by two decimal
points instead of only one, e.g.: current block [
•
BGxx], previous block [
••
BGxx], etc.
C.1 Addressing G and M Functions
Symbol See Description
[
•
BGxx] 2.2.1.1 G function addressing
[
•
BMxx] 2.2.1.2 M function addressing
C.2 Addressing a List of Bits
Symbol See Description
[
•
IBI(i)] 2.2.1.3 List of arguments I, J and K programmed in the current block
[
•
IBP(i)] 2.2.1.3 List of arguments P, Q and R programmed in the current block
[
•
IBX(i)] 2.2.1.3 List of axes programmed in the current block
[
•
IBX1(i)] 2.2.1.3 List of axes programmed from the beginning of the programme to the current
block
[
•
IBX2(i)] 2.2.1.3 List storing the last axes programmed XYZ or UVW
[
•
IBXM(i)] 2.2.1.3 Mirroring or not of the axes
C.3 Addressing a Value
Symbol See Description
[
•
RD] 2.2.2.1 Tool correction number
[
•
RDX] 2.2.2.1 Tool axis orientation (G16)
[
•
REC] 2.2.2.1 Spindle orientation
[
•
RED] 2.2.2.1 Angular offset
[
•
RF] 2.2.2.1 Feed rate
[
•
RG4] 2.2.2.1 Programmed dwell (G04 F..)
[
•
RG80] 2.2.2.1 Number of the calling function in the subroutine call by G function
