Reading the Programme Status Access Symbols
en-938872/2 2 - 5
2
Example
%100
N10 G00 G52 Z0 G71
N..
N40 G97 S1000 M03 M41
N50 M60 G77 H9000 Tool check subroutine call
N..
N350 M02
%9000
VAR
[GPLAN] [MGAMME] [MSENS] [GINCH] [GABS]
[XRETOUR] [YRETOUR] [ZRETOUR]
ENDV
$ CONTEXT SAVE
N10 [GPLAN]=17
*
[
•
BG17]
[GPLAN]=18
*
[
•
BG18]+[GPLAN] Interpolation plane
[GPLAN]=19
*
[
•
BG19]+[GPLAN]
N20 [MGAMME]=40
*
[
•
BM40] Speed range
[MGAMME]=41
*
[
•
BM41]+[MGAMME]
N30 [MSENS]=03
*
[
•
BM03]
[MSENS]=04
*
[
•
BM04]+[MSENS] Direction of rotation
[MENS]=05
*
[
•
BM05]+[MSENS]
N40 [GINCH]=70
*
[
•
BG70] Inches
[GINCH]=71
*
[
•
BG71]+[GINCH]
N50 [GABS]=90
*
[
•
BG90] Absolute
[GABS]=91
*
[
•
BG91]+[GABS]
[XRETOUR]=E70000
[YRETOUR]=E71000
[ZRETOUR]=E72000
N60 G90 G70 G00 G52 Z0
N70 G52 X100 Y100 M05 Tool check position
N80 G52 G10 Z-500
N90 G52 Z0
N100 G52 Z [ZRETOUR] Return to Z position
N110 G52 X [XRETOUR]
N120 G52 Y [YRETOUR]
G[GPLAN] M[MGAMME]
M[MSENS] G[GINCH] G[GABS] Restore context
