Reading the Programme Status Access Symbols
en-938872/2 2 - 7
2
[
•
IBXM(i)] Mirroring of the axes. The bit is set to indicate mirroring and is
reset to indicate no mirroring.
Index i = 1 to 9: same as the list of axes programmed in the
current block (see [
•
IBX(i)]).
[
•
IBI(i)] List of arguments I, J and K programmed in the current block.
Index i = 1 to 5.
List modal only in state G999.
i = 1: argument I
i = 2: argument J
i = 3: argument K
i = 4: in G21: J component address index 4
in G22: K component address index 4
i = 5: in G21: I component address index 5
in G22: J component address index 5
[
•
IBP(i)] List of arguments P, Q and R programmed in the current block.
Index i = 1 to 3.
List modal only in state G999.
i = 1: argument P
i = 2: argument Q
i = 3: argument R
