Creating and Managing Symbolic Variable Tables
en-938872/2 4 - 19
4
Note
Functions BSET and BCLR:
- must be the first words in the block (no sequence number),
- must be separated from the list of symbols by at least one space. However, there
must be no spaces in the list of symbols,
- are followed by the list of symbols to be enabled or inhibited. The symbols are
separated by «/».
Example
In block N120, only movements X10 and Z10 are executed. The movements on the
Y and B axes and the "post M" function M05 are inhibited (see Chapter 2 for indexes
(2) and (8) corresponding to Y and B respectively).
N..
N..
N.. G999 X10 Y10 Z10 B30 M05
BCLR [
•
IBX(2)] / [
•
IBX(8)] / [
•
BM05]
Disabled
N120 G997
