NUM 1020 - Page 72

4 - 28 en-938872/2
4.2.10 Programming Examples
Example 1
Use of BUILD for milling (XY plane). With radius correction, path from 1 to 6 then back
from 6 to 1.
Representation of machining
Y
X
4
5
6
3
2
G3
G2
G3
G2
1
Table built by the programme
1 0 0 0 0
2 22.268 8.104 0 0
3 28.243 14.081 18.846 17.501
1 35.905 35.13 0 0
2 65 30 50 30
1 65 20 0 0
1
GXY I J
Points
2
3
4
5
6
Values stored in
the table when
BUILD is executed
[NB] -1
G[TAB(1,I)]
X[TAB(2,I)]
