Recline Use
This Child Restraint has 10 recline positions.
Recline can be changed for child's comfort or to
improve installation of Child Restraint.
1 - Positions 1–5 (BLUE) are for rear facing use
with children 5–50 lbs.
2 - Positions 1–5 (RED) are for forward facing use
with children 25–65 lbs.
To Adjust Recline
3 - Press Recline Button (1) on either side of the
Child Restraint and move seat to desired
recline position. (2)
Release Recline Button, and check that Child
Restraint is locked in desired recline position.
If infant’s head falls forward, Child Restraint
must be reclined more. Use Infant Insert with
infants 5–11 lbs (2.3–5 kg) to improve the
recline angle for smaller infants.
To change recline position after installation,
uninstall Child Restraint, select new recline
position, and reinstall Child Restraint.
1
2
3
