a
b
1 - Remove Head Support Cover.
a Grasp Head Support Cover at top behind
Head Support Button.
b Peel Cover off Head Support; work on one
side then the other. Unsnap Cover and remove.
2 - Unsnap Seat Cover.
Remove Seat Cover from Calf Support.
3 - Remove Seat Cover from beneath Harness
Release Button frame.
a Grasp the Seat Cover at the top of the
Harness Release Button.
b Pull away from Button (toward seat back)
and up.
c Work cover out from under the Button frame.
4 - Remove Cover from Child Restraint.
a Start at bottom, near Calf Support, work
toward Buckle Holder. Pull Seat Cover out of
seat cover retaining channel.
b Unhook Cover beneath Buckle Tongue
Holder.
c Continue to the Tether.
d Repeat steps A through C for the other side.
5 - Flip cover over the top of the Child Restraint.
Slide Seat Cover off of the Tether.
a
b
1
2
3
4
5
64 RAVA instructions 65RAVA instructions
