Nvidia DGX Station A100 User Manual

DGX Station A100 Hardware Specifications
DGX Station A100 DU-10189-001 _v5.0.2|64
Component Qty Description
Data storage 3
7.68 TB and a cache/data U.2 NVME drive
OS storage 1 Boot M.2 NVME drive
E.3. Mechanical Specifications
Specification Value
Height 26.1” (639 mm)
Width 10.1” (256 mm)
Depth 20.4” (518 mm)
Gross weight 91 lbs (43.1 kg)
E.4. Power Specifications
RESTRICTION: The power source for DGX Station A100 must be 100V and cannot fall below 90V.
Input Comments
100-115VAC/15A,
115-120VAC/12A,
200-240VAC/10A, and
50/60Hz
The DGX Station A100 power consumption can reach 1,500 W (ambient
temperature 30°C) with all system resources under a heavy load.
Be aware of your electrical source’s power capability to avoid overloading
the circuit.
