DGX Station A100 DU-10189-001 _v5.0.2|27
Chapter4. Enable MIG Mode in DGX
Station A100
Here is some information about how you can enable the Multi-Instance GPU (MIG) mode.
1. By default, MIG mode is not enabled on the DGX Station A100.
For example, when you run nvidia-smi, the output shows that MIG mode is disabled:
$ nvidia-smi -i 0
+-----------------------------------------------------------------------------+
| NVIDIA-SMI 450.80.02 Driver Version: 450.80.02 CUDA Version: 11.0 |
|-------------------------------+----------------------+----------------------+
| GPU Name Persistence-M| Bus-Id Disp.A | Volatile Uncorr. ECC |
| Fan Temp Perf Pwr:Usage/Cap| Memory-Usage | GPU-Util Compute M. |
| | | MIG M. |
|===============================+======================+======================|
| 0 A100-SXM4-40GB Off | 00000000:36:00.0 Off | 0 |
| N/A 29C P0 62W / 400W | 0MiB / 40537MiB | 6% Default |
| | | Disabled |
+-------------------------------+----------------------+----------------------+
2. To enable the MIG mode for each GPU, run the nvidia-smi -i <GPU IDs> -mig 1
command.
3. Select the GPUs by using comma-separated GPU indexes, PCI Bus Ids, or UUIDs.
Here is some information to remember:
‣
If you do not specify a GPU ID, the MIG mode is applied to all the GPUs on the system.
$ sudo nvidia-smi -i 0 -mig 1
Enabled MIG Mode for GPU 00000000:36:00.0
All done.
$ nvidia-smi -i 0 --query-gpu=pci.bus_id,mig.mode.current --format=csv
pci.bus_id, mig.mode.current
00000000:36:00.0, Enabled
‣
If you are using MIG in a VM with GPU passthrough, you might need to reboot the VM to
allow the GPU to be in MIG mode.
Sometimes, for security reasons, the GPU reset is not allowed via the hypervisor. Here
is an example:
$ sudo nvidia-smi -i 0 -mig 1
Warning: MIG mode is in pending enable state for GPU 00000000:00:03.0:Not
Supported
Reboot the system or try nvidia-smi --gpu-reset to make MIG mode effective on
GPU 00000000:00:03.0
All done.
