LPCXpresso55S69 Development Board
1. Introduction
The LPCXpresso™ family of boards provides a powerful and flexible development system
for NXP's LPC Cortex®-M family of MCUs. They can be used with a wide range of
development tools, including NXP’s MCUXpresso IDE. The LPCXpresso55S69 board
(order code LPC55S69-EVK) is the evaluation and development platform for the LPC556x
family of MCUs.
See http://www.nxp.com/demoboard/LPC55S69-EVK for more information on this board,
including tutorial videos, development software and board hardware design files. Note:
the schematics for this board indicate components that are not installed by default
with a red cross.
The LPCXpresso55S69 includes the following features:
• LPC55S69 Dual Cortex-M33 core processor
• Onboard, high-speed USB, Link2 debug probe with CMSIS-DAP and SEGGER J-Link
protocol options
• UART and SPI port bridging from LPC55S69 target to USB via the onboard debug
probe
• Optional external debug probes with trace option (10 or 20 pin Cortex-M connectors)
Fig 1. LPCXpresso55S69
