Chapter 1
Introduction
This document describes MIMXRT1060/1064 Evaluation Kit (EVK) based on the i.MX RT1060/1064 processor from NXP
Semiconductor. The document includes system setup, debugging, and provides detailed information on the overall design and
usage of the EVK board from a hardware system.
1.1 Board overview
This EVK board is a platform designed to showcase the commonly used features of the i.MX RT1060/1064 Processor in a small,
low-cost package. The MIMXRT1060/1064 EVK board is an entry level development board that familiarizes the developer to the
processor before investing on resources for specific designs.
The features of the MIMXRT1060/1064 EVK board are listed in Board features.
The features of the MIMXRT1060/1064 EVK board are listed in Table 1.
Table 1. Board features
Processor NXP Processor MIMXRT1062DVL6A
MIMXRT1064DVL6A
DRAM Memory SDRAM 256 Mbit, 166 MHz IS42S16160J-6BLI
DCDC MPS MP2144GJ
LDO UNION
UM1550S-18
UM1750S-00
Mass Storage TF Card Slot
64 Mbit Quad SPI flash
512 Mbit Hyper flash
Display Interface LCD connector
Ethernet 10/100 Mbit/s Ethernet connector. PHY chip: KSZ8081RNB
USB USB 2.0 OTG connector
USB 2.0 host connector
Audio Connector 3.5 mm audio stereo headphone jack
Board-mounted microphone
Left and right speaker out connectors
S/PDIF interface (unpopulated )
Power Connector 5 V DC-jack
Debug Connector JTAG 20-pin connector (SWD by default)
OpenSDA with DAP-Link
Sensor
FXOS8700CQ: 6-Axis Ecompass (3-Axis Mag, 3-Axis Accel)
(Some boards are unpopulated)
Table continues on the next page...
NXP Semiconductors
MIMXRT1060/1064 Evaluation Kit Board Hardware User's Guide, Rev. 0, 06/2020
User's Guide 3 / 19
