J24 J25
D8/CLKO/ICP1 NC
D9/OC1A/PWM IOREF
D10/SPI_CS RESET
D11/OC2A/PWM/SPI_MOSI 3.3 V
D12/SPI_MISO 5 V
D13/SPI_CLK GND
GND GND
AREF
D14/I2C_SDA
D15/I2C_SCL
2.14 Camera module connector
i.MX RT1060/1064 supports one parallel CSI (Camera Sensor Interface). There is a camera module connector (J35) on the
MIMXRT1060/1064 EVK board. The CA031C based on OV7725 and CA111C based on MT9M114 are used directly.
J35 supports both MT9M114 and OV7725 camera module, but 3.3 V is a violation to MT9M114 spec 3.1 V. It
proved fine for evaluation/demo with 3.3 V supply, but in product design, it is recommended to adjust DCDC output
or add level shifter.
NOTE
2.15 User interface switch
There are four user interface switches on the MIMXRT1060/1064 EVK board.
• Power switch
• ON/OFF button
• Reset button
• USER button
2.15.1 Power switch
SW1 is a slide switch to control the power of the MIMXRT1060/1064 EVK board when the power supply is from J2.
• Sliding the switch to the ON position connects the 5 V power supply to the evaluation board main power system.
• Sliding the switch to the OFF position immediately removes all power from the board.
2.15.2 ON/OFF button
SW2 is the ON/OFF button for MIMXRT1060/1064 EVK board. A short pressing in OFF mode causes the internal power
management state machine to change state to ON. In ON mode, a short pressing generates an interrupt as a software-controllable
power-down. An approximate 5 seconds or more pressing causes a forced OFF. However, you can disconnect both the boot
mode inputs.
NXP Semiconductors
Specifications
MIMXRT1060/1064 Evaluation Kit Board Hardware User's Guide, Rev. 0, 06/2020
User's Guide 14 / 19
