Chapter 3
PCB information
The MIMXRT1060/1064 EVK board is uses the standard 4-layer technology. The material used is FR-4. The PCB stack-up
information is shown in Table 8.
Table 8. Board stack-up information
Layer Description Copper(Oz) Dielectric Thickness(mil)
1 Signal 1 —
Dielectric — 3
2 GND 1 —
Dielectric — 52
3 Power 1 —
Dielectric — 3
4 Signal 1 —
NXP Semiconductors
MIMXRT1060/1064 Evaluation Kit Board Hardware User's Guide, Rev. 0, 06/2020
User's Guide 16 / 19
