39
Adjusting the Print Status
22. Select Advanced Adj. then press the [ ] button.
[101]
[102]
23. Press the [ ] or [ ] button to select Yes, then press the OK button.
[103]
[104]
The printhead adjustment pattern is printed.
[105]
The printer scans the resulting printout as it is printed, and automatically calibrates
the printhead adjustment values.
When the calibration has finished, the printer returns online.
Printhead Adj
Advanced Adj.
Advanced Adj.
Yes
To Next Page
