Octave V 80 SE User Manual

24
7. ADVANCED FUNCTIONS
7.1. Linear mode
In Linear mode, the power amplifier section of the V 80 SE is connected to the internal preamplifier
and to the input selector switch. This is the V 80 SE's normal operating mode – as an integrated
amplifier. The mode selector [8] must be on Linear.
7.2. "Extern"-function: Separating the pre- and power amplifier
Being able to separate the pre and power amplifier provides you with a number of useful options.
The two most common of these are 1) inserting an external analogue signal processor/equalizer
and 2) using the V 80 SE as an independently adjustable power amplifier together with an external
preamplifier.
Two relays inside the V 80 SE are responsible for separating the pre and power sections. They are
actuated when the selector knob [8] is switched to the Extern position. You do not need to remove
any external links or jumpers.
Front panel switch settings
Rear panel connections
Master In Input to power amplifier when Extern function is on
Master Out Preamplifier output when Extern function is on
