14. TECHNICAL DATA
14.1. In- and Outputs
In- and outputs
Inputs
7 x RCA (including the Home Theatre Bypass input)
One RCA input can be fitted with the optional either MM or
MC Phono Input Board
1 x XLR
Outputs
1 x regulated Preamplifier output (RCA),
1 x Tape Record (RCA)
1 x Headphone output
1 x Loudspeaker output
The pre- and power amplifier sections of the V 80 SE can
be operated independently from each other as well
XLR Sensitivity
+6 dB relative to RCA
XLR pin assignment
1 = ground, 2 = positive, 3 = negative
Power amplifier
Output
2 x 120 W RMS, 150 W Peak Power into 4 ohms
Frequency response
10 Hz – 80 kHz
THD
0.1% at 10 W into 4 ohms
Signal-to-noise ratio
103 dB
Minimum load impedance
2 ohms
Gain
38 dB
Headphone amplifier
Output Voltage
10 V RMS into 300 ohms
Frequency response
10 Hz – 150 kHz
THD
0.0075%
Preamplifier
Input sensitivity
300 mV RCA and XLR
Input impedance
40 k ohms RCA; 25 k ohms XLR
Channel balance
0.5 dB to - 70 dB on volume control
Left/right crosstalk
60 dB
Input to input crosstalk
- 105 dB
Gain at pre out
+12 dB
General
Power consumption
< 30 W in Ecomode, 180 W idle, 500 W full power
Weight
23 kg
Fuse
For 230 mains: 3.15 A slow-blow H
Dimensions
Overall dimensions in mm
451 X 150 x 415 mm (W x H x D)
