11 Measuring Procedure
Instruction Manual Pentacam® AXL (G/70100/EN 1121 Rev04) 37 / 85
 Go to measurement “Adjustment” page 43.
During the measurement of both eyes the following messages may occur.
Note
The axial length values do not correspond to the values of the normal
population.
 Check the axial length values of both eyes.
The plausibility is marked by a yellow flagged QS value. This will be stored
in the Pentacam® AXL programme accordingly.
This symbol, related to the messages appears for example in the IOL
calculator.
 Click on this symbol to show the corresponding message.
You must check the corresponding measured value.
1 Message with instructions
Fig. 11-4: Pentacam® AXL: Proceed with 3D-Scan
1
Fig. 11-5: Message: Plausibility check
