5.FUEL SYSTEM
5-
Installation
Install fuel sensor to fuel tank.
Connect connector and hose.
Turn on fuel supply switch, and check whether functions of fuel meter is normal or not.
Fuel leakage is not allowed.
FUEL TANK
Fuel tank draining
Never perform this operation when the engine and/or the exhaust system is/are hot.
Never sue a hose pincher on injection system high pressure hoses.
Remove fuel tank cap and siphon gas in an approved fuel container.
Fuel tank removal
Remove the seat by lift 2 lock lever.
Remove the rear boby guard(right).
Remove the right guard.
Disable fuel pump by removing the electrical
connector from the fuel pump.
Remove fuel pump outlet hose.
Remove fuel pump retaining screws and hoops.
Remove the bolts of fuel tank retaining.
