6.DRIVE TRAIN
6-
FRONT DRIVE SHAFT
Removal
Remove the appropriate wheel hub.
Remove the guard plate of brake caliper
Remove the fixing clip of brake hose on
the knuckle.
Remove the shock absorber.
Remove the ball joint of tie rod from the
steering knuckle.
Remove the nuts of knuckle upper and
lower ball joint.
Remove the knuckle.
Pull drive shaft out of differential.
Inspection
Inspect the condition boots. If there is
any damage or evidence of leaking
lubricant, replace them.
Check splines for excessive wear.
Replace if necessary. If the splines on
plunging joint are worn, a check of
differential inner splines should be
done.
Check the ring at the end of drive
shaft. If wear is apparent, replace the
wear ring.
