7.STEERING SYSTEM
7-
3. Redirector Assembly
3.1 Remove the cover
3.2 Remove steering booster body retaining bolts
3.3 Remove the retaining bolts of Redirector
Assembly
3.4 Remove the tie Rod
Inspecting：Check Internal spline for wear, cracks or bending.Ensure universal
joints are not worn and move freely，Whether there is a rotation gap
Replace if necessary
Installing：The installation is the reverse of the removal pro-cedure
