OHAUS TD52P - Maintenance; T52 P Cleaning; T52 XW Cleaning; Technical Data

EN-5
4. MAINTENANCE
CAUTION: DISCONNECT THE UNIT FROM THE POWER SUPPLY BEFORE CLEANING.
4.1 Model T52P Cleaning
 The housing may be cleaned with a cloth dampened with a mild detergent if necessary.
 Do not use solvents, chemicals, alcohol, ammonia or abrasives to clean the housing or
control panel.
4.2 Model T52XW Cleaning
 Use approved cleaning solutions for the stainless-steel Indicator housing and rinse with water.
Dry thoroughly.
 Do not use solvents, chemicals, alcohol, ammonia or abrasives to clean the control panel.
5. TECHNICAL DATA
Materials
TD52XW Housing: stainless-steel
TD52P Housing: ABS plastic
Display window: polycarbonate
Keypad: polyester
Ambient conditions
The technical data is valid under the following ambient conditions:
Ambient temperature: -10°C to 40°C / 14°F to 104°F
Relative humidity: Maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to
50% relative humidity at 40°C.
Altitude: up to 2000m
Operability is assured at ambient temperatures between -10°C and 40°C.
TABLE 1 SPECIFICATIONS
Indicator Model
TD52P
TD52XW
Maximum displayed resolution
1:75,000
Maximum approved resolution
1:10,000
Maximum counting resolution
1:1,500,000
6. COMPLIANCE
Compliance to the following standards is indicated by the corresponding mark on the product.
Mark
Standard
This product complies with the applicable harmonized standards of EU Directives
2011/65/EU (RoHS), 2014/30/EU (EMC), 2014/35/EU (LVD) and 2014/31/EU (NAWI).
The EU Declaration of Conformity is available online at www.ohaus.com/ce.
EN 61326-1; AS/NZS 61010-1
UL Std. No. 61010-1
CAN/CSA-C22.2 No. 61010-1
