CHAPTER 5 PARTS LISTS & DIAGRAMS
Valor™ 2000 Series Service Manual 5-3 Ohaus Corporation www.ohaus.com
5.1 VALOR 2000 SCALES: HOUSING & INTERNAL PARTS
TABLE 5-1. VALOR 2000 SCALES: HOUSING & INTERNAL PARTS
Drawing Item
Description
1
Pan
2
Pan Support
3
Gasket Kit: Main Gasket, Load Cell Seal
Gasket, and Gasket Washers
4
Function Label
5
Housing, Top
6
Load Cell Assembly
7
Housing, Bottom
8
Main PCB, with LED
9
Back Display PCB, with LED
10
Power PCB
11
Feet, 4, Adjustable
12
Back Overlay
13
Cable Set, 3
14
Battery Bracket
15
Battery, Rechargeable
16
Hardware Kit
17
LFT Sealing Kit
18
Level Bubble
80
Adapter
Note: The Parts List is identical for all Valor 2000 models. For parts numbers, see your local
Ohaus distributor, or visit www. Ohaus.com.
