Paper handling > 23
6. Open the left and right Pin Tractor covers (1) and feed the con-
tinuous forms in the direction of the arrows, locating the sprocket
holes (2) in the forms onto the sprocket pins. Ensure that the
forms are properly aligned on the sprocket pins (3), then close the
covers.
7. Adjust the right Pin Tractor (1) to accommodate the width of the
continuous forms, taking care that the forms are held neither too
loosely nor too tightly between the Pin Tractors. Press the locking
lever (2) down to lock the right Pin Tractor in the desired position.
8. Press the FF/LOAD button. The continuous forms will be taken
into the printer and positioned at the first line print position and the
SEL indicator will illuminate.
