Paper handling > 26
4. Lift the Pin Tractor covers (1) and remove the forms.
5. Close the Pin Tractor covers.
Setting the paper thickness lever
There are 10 lever positions, the first 9 for printing purposes and the tenth
to facilitate ribbon replacement.
Set the Paper Thickness lever for different paper types as follows:
PAPER TYPE
LEvER PoSiTion
1 2 3 4 5 - 9
Cut sheet paper See below
52 - 80 gsm X
81 - 127 gsm X
128 - 156 gsm X
Envelope X
Carbon paper or Pressure-
sensitive paper (40 gsm)
See below
2 part X
3 part X
4 part X
5 part X
6 part X
