Consumables and accessories > 59
8. In the direction indicated by the arrows, insert the pins at both
ends of the ribbon cartridge (1) into the U grooves (2) in the printer
until the ribbon cartridge is fully locked.
NOTE
It may be easier to mount the ribbon cartridge in place if you align it
with the topside of the grooves. Also, a slightly loose ribbon may make
it easier to mount the ribbon cartridge.
9. Hold the ribbon cartridge (1) with your fingers pressing on its rib-
bon guide (2) and slope it upward and inward along the guide rails
until the ribbon guide (2) comes in line with the U slot at the top of
the cartridge.
