Oki B430

4. ADJUSTMENT
43984801TH Rev.1
79 /
Oki Data CONFIDENTIAL
Category (1st Line)
(16 Characters)
Item (1st Line)
(16 Characters)
Value
(2nd Line)
Default Function Valid Save
0X ADJST 0
1
2
3
4
5
6
7
-8
-7
-6
-5
-4
-3
-2
-1
*
[
ON DELAY OFFSET
]
ON DELAY OFFSET TABLE
SELECTION
At setting HEATON Signal Output Time,
set the value that the corresponding
table value has been added to the
resistor.
0: 0.0ms
1: 0.5ms
2: 1.0ms
3: 1.5ms
4: 2.0ms
5: 2.5ms
6: 3.0ms
7: 3.5ms
-8: -4.0ms
-7: -3.5ms
-6: -3.0ms
-5: -2.5ms
-4: -2.0ms
-3: -1.5ms
-2: -1.0ms
-1: -0.5ms
- -
By ENGINE TEST displaying, press
SELECT SW, SUBITEM is displayed on
the 1st Line.
- -
ENGINE
TEST
EP TEST OFF
PAPER
CONNECT
*
In this printer, this setting is not used.
- -
PRT DUTY 1/1
1/10
1/20
1/50
*
Set Duty that is used for Motor
Accelerating Test in the factory. Setting
as 1/n means that after 1 piece of paper
printing, it makes the engine idles away
for n-1 piece of paper amount.
- -
MODE 00
01
02
~
FD
FE
FF
*
The setting is irrevocable because it is
used for engine debug mode.
If set it out of default (00), the printing
stops.
- -
ENGINE
RESET
- -
-
Reset the following counters that are
used in engine part.
Drum Total Counter
•
Drum Counter
•
Printing Total Page Counter
•
But, Printing Total Page Counter is
only reset for the count under 500. (This
limit is not compliant in the case of
reset for PJL Command)
- -
After reset, printer returns to normal operating mode.
Note!
"
Start Position Setting of Printing
"
is only for shipment. Do not change the default value.
