Operator panel > 35
N
ETWORK
S
ETUP
This menu controls the operation of the printer’s network interface.
ITEM SETTINGS EXPLANATION
ENABLING DEFAULT
GATEWAY
WIRED
WIRELESS
(INFRASTRUCTURE)
WIRED ENABLE
DISABLE
TCP/IP ENABLE
DISABLE
Enables or disables this network protocol.
NETBIOS OVER TCP ENABLE
DISABLE
Sets Enable/Disable of NetBIOS over TCP protocol.
Display Conditions: TCP/IP should be enabled.
IP ADDRESS SET AUTO
MANUAL
Specifies whether IP address allocation is automatic
(DHCP) or manually assigned.
IPV4 ADDRESS xxx.xxx.xxx.xxx Current assigned IP address. To change, press OK and
use Menu buttons to increment 1st octet, then press
OK again to move on to next octet. When 4th octet has
been set, press OK again to register new address.
SUBNET MASK xxx.xxx.xxx.xxx Current assigned subnet mask. To change, proceed as
above.
GATEWAY ADDRESS xxx.xxx.xxx.xxx Current assigned gateway address. To change, proceed
as above.
WEB ENABLE
DISABLE
Enables or disables Web config. facility.
TELNET ENABLE
DISABLE
Enables or disables Telnet config. facility.
FTP ENABLE
DISABLE
Enables or disables communication via FTP.
IPSEC ENABLE
DISABLE
Sets Enable/Disable of IPSec. Enable via the web.
Enable: IPSec is available.
Disable: IPSec is not available.
SNMP ENABLE
DISABLE
Enables or disables SNMP protocol.
NETWORK SCALE NORMAL
SMALL
Selects network size.
When NORMAL is selected, printer can work effectively,
even when connected to a HUB that has a spanning
tree feature. However, printer start up time gets longer
when computers are connected with two or three small
LANs.
When SMALL is selected, computers can cover from two
or three small LANs to a large LAN, but may not work
effectively when connected to a HUB that has a
spanning tree feature.
GIGABIT NETWORK ENABLE
DISABLE
Sets whether to enable access with Gigabit Ethernet.
