42615101TH Rev.8 105 /
Oki Data CONFIDENTIAL
(Blue)
1
3
2
4.2.21 Fuser Unit
(1) Open the top cover 1.
(2) Rise the Fuser-Unit-Lock-Levers (two blue portions) 2 in the directions of the arrows to detach
the fuser unit 3.
Figure 4-2-21 Fuser Unit
