42615101TH Rev.8 108 /
Oki Data CONFIDENTIAL
1 42049501 Plate-Assy.-Base
Gear-Z24-50-HP
Stopper-Z45-48-HP
Gear-Planet-HP
Holder-Planet
Stopper-HP
Shaft-Hopping
End surface EM-30L Class C
Gear bottom surface
EM-30L Class C
The side of groove
EM-30L Class C
Cog surface abnd end surface
EM-30L Class C
Ratch portion(Hatching portion) EM-30L Class C
Post EM-30L Class A
Post EM-30L Class A
Both side EM-30L Class A
Both side EM-30L Class A
Bearring portion
EM-30L Class A
Bearring portion
EM-30L Class A
